Auxiliary Area Allocations
Address Name
Words Bits
A019 Previous Cause of Switching to Simplex Operation (Duplex CPU Systems only)
A01900 Duplex
Verifica-
tion Error
Switch
Flag
A01901 Duplex
Bus Error
Switch
Flag
A01902 Duplex Ini-
tialization
Error
Switch
Flag
A01903 CPU Unit
Setting
Switch
Flag
A01904 CPU Error
(WDT)
Switch
Flag
A01906 FALS
Instruc-
tion Error
Switch
Flag
A01908 Cycle
Time
Overrun
Switch
Flag
A01909 Program
Error
Switch
Flag
A01912 Fatal Inner
Board
Error
Switch
Flag
A01915 Memory
Error
Switch
Flag
524
Function
ON: A duplex verification error caused the
previous switch from duplex to simplex
operation.
ON: A duplex bus error caused the previ-
ous switch from duplex to simplex opera-
tion.
ON: An error during duplex initialization
caused the previous switch from duplex to
simplex operation and duplex operation
was never started.
ON: Changing the CPU Unit's switch from
USE to NO USE caused the previous
switch from duplex to simplex operation.
ON: A CPU Unit error (WDT) caused the
previous switch from duplex to simplex
operation.
ON: Execution of an FALS instruction
caused the previous switch from duplex to
simplex operation.
ON: Exceeding the cycle time caused the
previous switch from duplex to simplex
operation.
ON: A program error caused the previous
switch from duplex to simplex operation.
ON: A fatal Inner Board error caused the
previous switch from duplex to simplex
operation. (Process-control CPU Units
only)
ON: A memory error caused the previous
switch from duplex to simplex operation.
Settings Status Status
after
mode startup
change
ON: Switched to Held Held
simplex opera-
tion for duplex
verification error
OFF: Normal
ON: Switched to
simplex opera-
tion for duplex
bus error
OFF: Normal
ON: Switched to
simplex opera-
tion for duplex
initialization
error
OFF: Normal
ON: Switched to
simplex opera-
tion for CPU set-
ting
OFF: Normal
ON: Switched to
simplex opera-
tion for CPU
error
OFF: Normal
ON: Switched to
simplex opera-
tion for FALS
instruction
OFF: Normal
ON: Switched to
simplex opera-
tion for cycle
time error
OFF: Normal
ON: Switched to
simplex opera-
tion for program
error
OFF: Normal
ON: Switched to
simplex opera-
tion for fatal
Inner Board
error
OFF: Normal
ON: Switched to
simplex opera-
tion for memory
error
OFF: Normal
Appendix B
Timing Related
at flags,
settings
Data from ---
A023 is
stored
when
duplex
operation
is recov-
ered.
