PLC Setup Coding Sheets for Programming Console
164@@@@
Value (hex)
A 00
to
FF
Value (hex)
B 00
to
FF
165@@@@
RS-232C Port
Value (hex)
A 00
01
to
FF
Value (hex)
B 0
1
2
Value (hex)
C 0
1
166@@@@
RS-232C Port
Value (hex)
A 0000
0001
to
0007
195@@@@ (Single CPU Systems only)
A
Value (hex)
A 0000
0001
A
B
No-protocol Mode End Code
00
to
FF
No-protocol Mode Start Code
00
to
FF
A
B
C
No-protocol Mode reception data volume
256
1
to
256
No-protocol Mode end code setting
None (Specify the amount of data being received)
Yes (Specify the end code)
End code is set to CF+LF
No-protocol Mode start code setting
None
Yes
A
Maximum Unit No. in NT Link Mode
No. 0
No. 1
to
No. 7
Scheduled Interrupt Time Unit
10 ms
1.0 ms
