Duplex CPU Units
Operational
Restrictions
Instruction
Restrictions
130
contents are different, write processing to the Memory Cards may not be
completely correctly.
• Duplex operation is possible for EM file memory.
• Interrupts (including scheduled interrupt tasks, external interrupt tasks,
and power OFF interrupt tasks) cannot be used.
• Parallel processing for peripheral servicing (Parallel Processing Mode
and Peripheral Servicing Priority Mode) cannot be executed.
• The clock function is synchronized with the active CPU Unit.
• Instructions with the immediate refresh option (!) cannot be used. (The
IORF instruction, however, is available.)
• The accuracy of timer instructions (TIM, TIMX, TIMH(015), TIMHX(551),
TMHH(540), TMHHX(552), TTIM(087), TTIMX(555), TIMW(813),
TIMWX(816), TMHW(815), TMHWX(817), TIML(542), TIMLX(553),
MTIM(543), and MTIMX(554)) is less than for CS1-H CPU Units. The
accuracy is as follows:
TIM, TIMX, TIMH(015), TIMHX(551), TMHH(540), TMHHX(552),
TTIM(087), TTIMX(555), TIML(542), TIMLX(553), MTIM(543),
MTIMX(554), TIMW(813), TIMWX(816), TMHW(815), TMHWX(817):
±(10 ms + cycle time)
Note If the mode is changed from Duplex Mode to Simplex Mode during execution
of a timer instruction, the accuracy in the first cycle following the mode switch
is less than normal (as shown below).
TIM, TIMX, TIMH(015), TIMHX(551), TTIM(087), TTIMX(555), TIML(542),
TIMLX(553), MTIM(543), MTIMX(554), TIMW(813), TIMWX(816),
TMHW(815), TMHWX(817) : ±(10 ms + cycle time) ±10 ms
TMHH(540), TMHHX(552) : ±(10 ms + cycle time) ±20 ms
Reference: Timer accuracy for the CS1-H is as follows:
TIM, TIMX, TIMH(015), TIMHX(551), TTIM(087), TTIMX(555), TIML(542),
TIMLX(553), MTIM(543), MTIMX(554), TIMW(813), TIMWX(816),
TMHW(815), TMHWX(817) : 0 to −10 ms
TMHH(540), TMHHX(552) : 0 to −1 ms
• PV refresh operations during timer instruction jumps, or while a block pro-
gram is stopped, are described below. (Operation is different from CS1-H
CPU Units.)
a) TIM, TIMX, TIMH(015), TIMHX(551), TMHH(540), TMHHX(552),
TTIM(087), TTIMX(555):
When a jump is executed for a JMP, CJMP, or CMPN-JME instruc-
tions, the timer PV is not refreshed (unlike CS1-H CPU Units). The
next time the instruction is executed (i.e., the next time the jump is not
made) the timer is refreshed for the period of time that elapsed since
it was last refreshed.
b) TIMW(813), TIMWX(816), TMHW(815), and TMHWX(817):
The timer PV is not refreshed when the BPRG instruction input condi-
tion is OFF or when the block program is paused by the BPPS instruc-
tion. (It is refreshed for CS1-H CPU Units.)
• Background execution cannot be used for text string processing instruc-
tions, table data instructions, or data shift instructions.
• Interrupt control instructions (MSKS, MSKR, CLI) and peripheral servicing
disable/enable instructions (IOSP/IORS) cannot be used. (They will be
executed as NOPs.)
Section 3-1
