Auxiliary Area Allocations
Address Name
Words Bits
A344 All EM File
Memory
Starting
Bank
A345 A34500 FB Pro-
gram Data
Flag
(Unit ver-
sion 4.0 or
later)
A34501 Symbol
Table File
Flag
(Unit ver-
sion 4.0 or
later)
A34502 Comment
File Flag
(Unit ver-
sion 4.0 or
later)
A34503 Program
Index File
Flag
(Unit ver-
sion 4.0 or
later)
A346 All Number of
and Remain-
A347 ing Words
to Transfer
Function
Contains the starting bank number
of EM file memory (bank number of
the first formatted bank). All EM
banks from this starting bank to the
last bank in EM are formatted for
use as file memory.
To convert the EM Area for use as
file memory, first set the PLC
Setup's EM File Memory Function
setting to 1, set the PLC Setup's EM
File Memory Starting Bank setting (0
to 18), and then format the EM Area
from a Programming Device
The PLC Setup's EM file memory
settings won't agree with the actual
settings unless the EM Area is for-
matted after the PLC Setup's EM file
memory settings have been
changed. In that case, the actual
settings can be determined with this
word.
Turns ON if the FB program memory
contains FB program data.
Turns ON when the comment mem-
ory contains a symbol table file.
Turns ON when the comment mem-
ory contains a comment file.
Turns ON when the comment mem-
ory contains a program index file.
These words contain the 8-digit
hexadecimal number of words
remaining to be transferred by
FREAD(700) or FWRIT(701). When
one of these instructions is exe-
cuted, the number of words to be
transferred is written to A346 and
A347.
While the data is being transferred,
the value in these words is decre-
mented.
A326 contains the rightmost 4-digits
and A347 contains the leftmost 4-
digits.
Check the content of these words to
determine whether or not the
planned number of words have been
transferred successfully.
Settings Status
after
mode
change
0000 to 0018 Held
hex
Bank 0 to 18
Held
Data remaining Held
in transfer
Appendix B
Status at Timing Related
startup flags,
settings
Held When EM PLC
file for- Setup
matting is (EM File
performed Memory
Func-
tion set-
ting and
EM File
Memory
Starting
Bank
setting)
Held When the
program
is down-
loaded
Cleared Written as ---
FREAD or
FWRIT is
being exe-
cuted.
Decre-
mented as
data is
actually
trans-
ferred.
