Configuration Devices
Power Supply Units
Duplex Unit
I/O Control Unit
Other Devices
38
Two CS1D Power Supply Units are required for a duplex power supply config-
uration.
Name
CS1D Power Supply
Units
One Duplex Unit is required on the CPU Rack.
Name
Duplex Unit
(Especially for a Duplex CPU,
Dual I/O Expansion System)
Duplex Unit
(Especially for a Duplex CPU,
Single I/O Expansion System)
Name
CS1D I/O Control Unit
(Especially for a Duplex CPU,
Dual I/O Expansion System)
Name
Memory Cards HMC-EF183
HMC-EF283
HMC-EF583
HMC-AP001
Programming Con- C200H-PRO27-E
soles
Programming Con- CS1W-KS001
sole Key Sheet
Programming Con- CS1W-CN224
sole Connecting
Cables
CS1W-CN624
Programming Device CS1W-CN118
Connecting Cables
(for peripheral port)
CS1W-CN226
CS1W-CN626
Model
CS1D- 100 to 120 V AC; 200 to 240 V AC (RUN
PA207R output)
Output capacity:
5 V DC at 7 A; 26 V DC at 1.3 A
CS1D-PD024 24 V DC
Output capacity: 5 V DC at 4.3 A;
26 V DC at 0.56 A
CS1D-PD025 24 V DC
Output capacity: 5 V DC at 5.3 A;
26 V DC at 1.3 A
Model
CS1D-DPL02D Required in a Duplex CPU System.
Can be replaced online.
CS1D-DPL01 Required in a Duplex CPU System.
Model
CS1D-IC102D Two Units (or one) are required to
expand a Duplex CPU, Dual I/O
Expansion System.
Model
Flash memory, 128 MB
Flash memory, 256 MB
Flash memory, 512 MB
Memory Card Adapter
An English Keyboard Sheet (CS1W-
KS001-E) is required.
For C200H-PRO27-E
Connects the CQM1-PRO27-E Pro-
gramming Console. (Length: 2.0 m)
Connects the CQM1-PRO27-E Pro-
gramming Console. (Length: 6.0 m)
Connects IBM PC/AT or compatible
computers.
D-Sub 9-pin receptacle (For convert-
ing between RS-232C cable and
peripherals) (Length: 0.1 m)
Connects IBM PC/AT or compatible
computers.
D-Sub 9-pin (Length: 2.0 m)
Connects IBM PC/AT or compatible
computers.
D-Sub 9-pin (Length: 6.0 m)
Section 2-2
Specifications
Specifications
Specifications
Specifications
