Omron SYSMAC CS1D-PD Series Operation Manual page 466

Error Processing
Error Program- Error
ming Con- flags in
sole Auxiliary
display Area
CS-series CPU BU A40207:
CPU Bus ERR CS-series
Unit error CPU Bus
Unit Error
Flag
Special SIOU ERR A40206:
I/O Unit Special
error I/O Unit
Error Flag
Basic I/O DENSITY A40212:
Unit error I/O ERR Basic I/O
Unit Error
Flag
Battery BATT LOW A40204:
error Battery
Error Flag
CS-series CPU BU A40203:
CPU Bus STUP CS-series
Unit Setup CPU Bus
error Unit Set-
ting Error
Flag
Special SIOU A40202:
I/O Unit SETUP Special
Setup I/O Unit
error Setting
Error Flag
Interrupt INTRPT A40213:
task error ERR Interrupt
Task
Error Flag
426
Error Flags
code (in and
A400) word
data
0200 to A417: An error occurred in a data exchange
020F CS- between the CPU Unit and a CS-
series series CPU Bus Unit.
CPU Bus
The corresponding flag in A417 is
Unit
turned ON to indicate the problem
Error,
Unit. Bits A41700 to A41715 corre-
Unit
spond to unit numbers 0 to F.
Number
Flags
0300 to A418 to An error occurred in a data exchange
035F, or A423: between the CPU Unit and a Special
03FF Special I/O Unit.
I/O Unit
The corresponding flag in A418 to
Error,
A423 is turned ON to indicate the
Unit
problem Unit. Bits A41800 to A42315
Number
correspond to unit numbers 0 to 95.
Flags
009A A408: An error occurred in the data
Basic I/O exchange between the CPU Unit and
Unit a Basic I/O Unit.
error, slot
Note: A408 contains the slot num-
number
ber where the error occurred.
00F7 --- This error occurs when the PLC
Setup has been set to detect battery
errors and the CPU Unit's backup
battery is missing or its voltage has
dropped.
0400 to A427: An installed CS-series CPU Bus Unit
040F CS- does not match the CS-series CPU
series Bus Unit registered in the I/O table.
CPU Bus
The corresponding flag in A427 will
Unit Set-
be ON. Bits 00 to 15 correspond to
ting
unit numbers 0 to F.
Error,
Unit
Number
Flags
0500 to A428 to An installed Special I/O Unit does
055F A433: not match the Special I/O Unit regis-
Special tered in the I/O table.
I/O Unit
The corresponding flag in A428 to
Setting
A433 will be ON. Bits A42800 to
Error,
A43315 correspond to unit numbers
Unit
0 to 95.
Number
Flags
008B A426: An attempt was made to refresh I/O
Interrupt for a Special I/O Unit with IORF(097)
Task within an interrupt task while cyclic
Error, I/O refresh processing was being
Task performed for the same Special I/O
Number Unit. Detecting interrupt task errors
must be enabled in the PLC Setup to
detect this error (redundant refresh-
ing).
Probable cause
Check the Unit indicated in A417.
Refer to the Unit's operation manual
to find and correct the cause of the
error. Restart the Unit by toggling its
Restart Bit or turn the power OFF
and ON again.
Replace the Unit if it won't restart.
Check the Unit indicated in A418 to
A423. Refer to the Unit's operation
manual to find and correct the cause
of the error. Restart the Unit by tog-
gling its Restart Bit or turn the power
OFF and ON again.
Replace the Unit if it won't restart.
Mount the I/O Unit in the Backplane.
If the error is not recurs, replace the
I/O Unit.
Check battery and replace if neces-
sary. Change the PLC Setup setting
if battery-free operation is being
used.
Change the registered I/O tables.
Review the program and either dis-
able detecting interrupt task errors or
prevent redundant refreshing from
occurring.
Section 10-2
Possible remedy
