System Configuration
CS1D-BC052 CPU
Backplane for
Duplex CPU Systems
CS1W-CN@@3
CS-series Connecting
Cable
CS1D-BI092
Expansion Backplane
12 m max.
CS1W-CN@@3
CS1D-BI092
CS1D-CPU@@HA/P/H
CPU Units for
CS1D-DPL01
Duplex CPU Systems
Duplex Unit
Maximum of 5 Units can be mounted.
· CS-series Basic I/O Units
CS1D-PA/PD@@@@
· CS-series Special I/O Units and CPU
Power Supply Units
Bus Units
Note: C200H Units cannot be mounted.
Maximum of 9 Units can be mounted.
· CS-series Basic I/O Units
CS1D-PA/PD@@@@
· CS-series Special I/O Units and CPU
Power Supply Units
Bus Units
Note: C200H Units cannot be mounted.
CS1D-BC082S
CPU Backplane
for Single CPU Systems
CS1D CPU Rack
Maximum of 8 Units can be mounted.
· CS-series Basic I/O Units
· CS-series Special I/O Units and CPU
Bus Units
Note: C200H Units cannot be mounted.
CS1D
Expansion
Rack
The maximum number of Expansion Racks is as follows:
CS1D-CPU6@HA/SA/P/H/S: Up to 7 Racks total
CS1D
CS1D-CPU44SA/S: Up to 3 Racks total
Expansion
CS1D-CPU42S: Up to 2 Racks total
Rack
CS1D
Expansion
Rack
CS1D
Expansion
Rack
Section 1-2
CS1D-CPU@@SA/S
CPU Unit for
Single CPU Systems
CS1D-PA/PD@@@
Power Supply Units
