Omron SYSMAC CS1D-PD Series Operation Manual page 144

Basic I/O Units
2-11-2 Interrupt Input Units
Dimensions
CS1W-INT01
2-11-3 High-speed Input Units
Functions
High-speed Inputs Units
Components
104
An Interrupt Input Unit can be used to input interrupts for a Single CPU Sys-
tem. With a Duplex CPU System, however, interrupt inputs cannot be used,
i.e., the Interrupt Input Unit will function only as a standard 16-point Input Unit.
Model
Model Specifications
CS1W-INT01 24 V DC 16 inputs
C200H Interrupt Input Units cannot be used.
20-pin terminal block
CS
130
35
The CS1W-IDP01 High-speed Input Unit enables inputting pulse signals that
are shorted than the cycle time of the CPU Unit.
Model
CS1W-IDP01 High-speed Input Unit
C200H Input Units cannot be used.
No. of Units mountable
to CPU Rack
2 max.
124
147
Name Specifications
24 V DC, 16 inputs
Input indicators
CS
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
Section 2-11
Reference
488
Reference
489
