Auxiliary Area Allocations
Addresses Name
Word Bit
A732 to Power ON
A734 Clock
Data 5
(CS1D-
CPU@@SA
and CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A735 to Power ON
A737 Clock
Data 6
(CS1D-
CPU@@SA)
Power OFF
Time His-
tory Data #1
(CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A738 to Power ON
A740 Clock
Data 7
(CS1D-
CPU@@SA)
Power OFF
Time His-
tory Data #2
(CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A741 to Power ON
A743 Clock
Data 8
(CS1D-
CPU@@SA)
Power OFF
Time His-
tory Data #3
(CS1D
Duplex-CPU
Systems
with unit
version 1.2
or later)
A744 to Power ON
A746 Clock
Data 9
(CS1D-
CPU@@SA)
Power OFF
Time His-
tory Data #4
(CS1D
Duplex-CPU
Systems
with unit ver-
sion 1.2 or
later)
Function
This is the history data at Startup Time.
A73200 to A73207: Second (00 to 59)
A73208 to A73215: Minute (00 to 59)
A73300 to A73307: Hour (00 to 23)
A73308 to A73315: Day of month (01 to
31)
A73400 to A73407: Month (01 to 12)
A73408 to A73415: Year (00 to 99)
For the CPU@@SA, this is the history
data at Startup Time.
For the CS1D Duplex-CPU Systems,
this is the history data at Power OFF
Time.
A73500 to A73507: Second (00 to 59)
A73508 to A73515: Minute (00 to 59)
A73600 to A73607: Hour (00 to 23)
A73608 to A73615: Day of month (01 to
31)
A73700 to A73707: Month (01 to 12)
A73708 to A73715: Year (00 to 99)
For the CPU@@SA, this is the history
data at Startup Time.
For the CS1D Duplex-CPU Systems,
this is the history data at Power OFF
Time.
A73800 to A73807: Second (00 to 59)
A73808 to A73815: Minute (00 to 59)
A73900 to A73907: Hour (00 to 23)
A73908 to A73915: Day of month (01 to
31)
A74000 to A74007: Month (01 to 12)
A74008 to A74015: Year (00 to 99)
For the CPU@@SA, this is the history
data at Startup Time.
For the CS1D Duplex-CPU Systems,
this is the history data at Power OFF
Time.
A74100 to A74107: Second (00 to 59)
A74108 to A74115: Minute (00 to 59)
A74200 to A74207: Hour (00 to 23)
A74208 to A74215: Day of month (01 to
31)
A74300 to A74307: Month (01 to 12)
A74308 to A74315: Year (00 to 99)
For the CPU@@SA, this is the history
data at Startup Time.
For the CS1D Duplex-CPU Systems,
this is the history data at Power OFF
Time.
A74400 to A74407: Second (00 to 59)
A74408 to A74415: Minute (00 to 59)
A74500 to A74507: Hour (00 to 23)
A74508 to A74515: Day of month (01 to
31)
A74600 to A74607: Month (01 to 12)
A74608 to A74615: Year (00 to 99)
Settings Status Status at
after startup
mode
change
See at left Held Held
See at left Held Held
See at left Held Held
See at left Held Held
See at left Held Held
Appendix B
Timing Related
Flags,
Settings
When
power is
turned
ON
When
power is
turned
ON
When
power is
turned
ON
When
power is
turned
ON
When
power is
turned
ON
