Configuration Devices
Devices
CPU Units
CPU Backplanes
Two CS1D CPU Units of the same model are required when using Duplex
CPU Units in a Duplex CPU System.
Name Model
CPU Units for CS1D-CPU67HA I/O bits: 5,120; program capacity: 250 Ksteps;
Duplex CPU
System
CS1D-CPU68HA I/O bits: 5,120; program capacity: 400 Ksteps;
CS1D-CPU65H
CS1D-CPU67H
CPU Units for CS1D-CPU44SA I/O bits: 1,280; program capacity: 30 Ksteps;
Single CPU Sys-
tem
CS1D-CPU67SA I/O bits: 5,120; program capacity: 250 Ksteps;
CS1D-CPU42S
CS1D-CPU44S
CS1D-CPU65S
CS1D-CPU67S
Name
CPU Backplane for Duplex
CPU Systems
(Especially for a Duplex CPU,
Dual I/O Expansion System)
CPU Backplane for Duplex
CPU Systems
(Especially for a Duplex CPU,
Single I/O Expansion System)
CPU Backplane for Single
CPU System
Specifications
Data memory: 448 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 13 banks)
Data memory: 832 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 25 banks)
I/O bits: 5,120; program capacity: 60 Ksteps;
Data Memory: 128 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 3 banks)
I/O bits: 5,120; program capacity: 250 Ksteps;
Data Memory: 448 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 13 banks)
Data memory: 64 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 1 banks)
Data Memory: 448 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 13 banks)
I/O bits: 960; program capacity: 10 Ksteps;
Data Memory: 64 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 1 bank)
I/O bits: 1,280; program capacity: 30 Ksteps;
Data Memory: 64 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 1 bank)
I/O bits: 5,120; program capacity: 60 Ksteps;
Data Memory: 128 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 3 banks)
I/O bits: 5,120; program capacity: 250 Ksteps;
Data Memory: 448 Kwords
(DM: 32 Kwords; EM: 32 Kwords x 13 banks)
Model
CS1D-BC042D Duplex Connecting Cable:3 slots
Single Connecting Cable:4 slots
No Expansion:5 slots
CS1D-BC052 5 slots
CS1D-BC082S 8 slots
