Auxiliary Area Allocations
Addresses Name
Word Bit
A620 A62001 Communi-
cations
Unit 0,
Port 1
Settings
Changing
Flag
A62002 Communi-
cations
Unit 0,
Port 2
Settings
Changing
Flag
A62003 Communi-
cations
Unit 0,
Port 3
Settings
Changing
Flag
A62004 Communi-
cations
Unit 0,
Port 4
Settings
Changing
Flag
A621 to A62100 Communi-
A635 to cations
A63504 Units 0 to
15, Ports
1 to 4 Set-
tings
Changing
Flag
A636 A63601 Communi-
cations
Board
Port 1
Settings
Changing
Flag
A63602 Communi-
cations
Board
Port 2
Settings
Changing
Flag
A63603 Communi-
cations
Board
Port 3
Settings
Changing
Flag
A63604 Communi-
cations
Board
Port 4
Settings
Changing
Flag
568
Function
The corresponding flag will be ON
when the settings for that port are being
changed.
The flag will be turned ON when
STUP(237) is executed and it will be
turned OFF by an event issued from the
Serial Communications Unit after the
settings have been changed.
It is also possible for the user to indi-
cate a change in serial port settings by
turning these flags ON.
Same as above.
The corresponding flag will be ON
when the settings for that port are being
changed.
The flag will be turned ON when
STUP(237) is executed and it will be
turned OFF by an event issued from the
Serial Communications Board after the
settings have been changed.
It is also possible for the user to indi-
cate a change in serial port settings by
turning these flags ON.
(Single CPU Systems only)
Settings Status Status at
after startup
mode
change
ON: Changing Held Cleared
OFF: Not
changing
ON: Changing Held Cleared
OFF: Not
changing
ON: Changing Held Cleared
OFF: Not
changing
ON: Changing Held Cleared
OFF: Not
changing
ON: Changing Held Cleared
OFF: Not
changing
1: Changing Retained Cleared
0: Not chang-
ing
1: Changing Retained Cleared
0: Not chang-
ing
1: Changing Retained Cleared
0: Not chang-
ing
1: Changing Retained Cleared
0: Not chang-
ing
Appendix B
Timing Related
Flags,
Settings
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
--- ---
