Omron SYSMAC CS1D-PD Series Operation Manual page 526

Specifications of Basic I/O Units and High-density I/O Units
CS1W-IA211 200-V AC Input Unit (16 points)
Rated Input Voltage
Allowable Input Voltage
Range
Input Impedance
Input Current
ON Voltage/ON current
OFF Voltage/OFF current
ON Response Time
OFF Response Time
No. of Circuits
Number of Inputs ON Simulta-
neously
Insulation Resistance
Dielectric Strength
Internal Current Consumption 110 mA 5 V DC max.
Weight
Circuit Configuration
Terminal Connections
Note 1. The Input ON and OFF response times for Basic I/O Units can be set to 0 ms, 0.5 ms, 1 ms, 2 ms,
4 ms, 8 ms, 16 ms, or 32 ms in the PLC Setup. When the response times have been set to 0 ms, the
ON response time will be 10 ms maximum and the OFF response time will be 40 ms maximum due
to internal element delays.
2. Terminal numbers A0 to A9 and B0 to B9 are used in this manual, but they are not printed on the Unit.
486
200 to 240 V AC, 50/60 Hz
170 to 264 V AC (50/60 Hz)
21 kΩ (50 Hz), 18 kΩ (60 Hz)
10 mA typical (at 200 V AC)
120 V AC min.
40 V AC max.
18 ms max. when PLC Setup on default setting (8 ms) (See note.)
48 ms max. when PLC Setup on default setting (8 ms) (See note.)
16 points (8 points/common, 2 commons)
100% simultaneously ON (for 230 V AC). Refer to the diagram below.
16
12
8
No. of inputs ON
simultaneously
4
0
0 10
20 MΩ between external terminals and the GR terminal (500 V DC)
2,000 V AC between the external terminals and the GR terminal for 1 minute at a leakage
current of 10 mA max.
260 g max.
820 Ω 1 MΩ
IN0
to
0.15 µF
IN7
220 Ω
COM0
Input indicator
820 Ω 1 MΩ
IN8
to
0.15 µF
IN15
220 Ω
COM1
0
2
4
200 to 240 VAC
6
COM0
8
10
12
200 to 240 VAC
14
COM1
20 30 40 50
Ambient temperature
A0 1
B0
A1 3
B1
A2 5
B2
A3 7
B3
A4 NC
B4
A5 9
B5
A6 11
B6
A7 13
B7
A8 15
B8
A9 NC
B9
Appendix A
230 VAC
240 VAC
264 VAC
60 (°C)
