Auxiliary Area
Name
Unit Removal without a Pro-
gramming Device Function
Setting Flag
Removal/Addition of Units
without a Programming
Device Setting Flag
Turn ON Error Unit Number
Flag when Removing a Spe-
cial Unit Setting Flag
Communications Port Auto-
allocation Instruction
Non-fatal Duplex Error Flag
Duplex Power Supply Information
■
Name
Duplex Power Supply Unit
Error Flag
Error Power Supply Unit
Location
288
Address
A80401 ON: The unit version of the standby CPU Unit is earlier than
the unit version of the active CPU Unit and the active CPU
Unit uses a PLC Setup setting (Unit Removal without a Pro-
gramming Device Function Setting) that is not supported by
the standby CPU Unit.
A80402 ON: The unit version of the standby CPU Unit is earlier than
the unit version of the active CPU Unit and the active CPU
Unit uses a PLC Setup setting (Removal/Addition of Units
without a Programming Device Setting) that is not supported
by the standby CPU Unit.
A80403 ON: The unit version of the standby CPU Unit is earlier than
the unit version of the active CPU Unit and the active CPU
Unit uses a PLC Setup setting (Turn ON Error Unit Number
Flag when Removing a Special Unit Setting) that is not sup-
ported by the standby CPU Unit.
A80404 ON: The unit version of the standby CPU Unit is earlier than
the unit version of the active CPU Unit and the active CPU
Unit uses an instruction (automatically allocating the com-
munications port) that is not supported by the standby CPU
Unit.
A40214 ON: One of the following errors occurred: Non-fatal duplex
error, duplex verification error, duplex bus error, duplex
power supply unit error, or duplex communications error
Address
A31602 ON: An error occurred in the Power Supply Unit or power sup-
ply system on a duplex CPU Rack, Expansion Rack, or Long-
distance Expansion Rack.
A31900 to When an error in a Power Supply Unit results in an error in the
A31915 5-V/26-V output, one of the following bits will turn ON to show
the location of the Power Supply Unit with the error.
A31900: Right Power Supply Unit on CPU Rack (rack 0).
A31901: Left Power Supply Unit on CPU Rack (rack 0).
A31902: Right Power Supply Unit on Expansion Rack (rack 1).
A31903: Left Power Supply Unit on Expansion Rack (rack 1).
...
A31914: Right Power Supply Unit on Expansion Rack (rack 7).
A31915: Left Power Supply Unit on Expansion Rack (rack 7).
A32000 to When the voltage on the primary side of the Power Supply Unit
A32015 drops or is interrupted, one of the following bits will turn ON to
show the location of the Power Supply Unit with the error.
A32000: Right Power Supply Unit on CPU Rack (rack 0).
A32001: Left Power Supply Unit on CPU Rack (rack 0).
A32002: Right Power Supply Unit on Expansion Rack (rack 1).
A32003: Left Power Supply Unit on Expansion Rack (rack 1).
...
A32014: Right Power Supply Unit on Expansion Rack (rack 7).
A32015: Left Power Supply Unit on Expansion Rack (rack 7).
Description
Description
Section 8-11
Access
Read-only
Read-only
Read-only
Read-only
Read-only
Access
Read-only
Read-only
Read-only
