Wiring Methods
CS-series 96-point I/O
Units

Wire Sizes

Wiring Procedure

1,2,3...
The following connectors are recommended for attachment to CS-series 96-
point I/O Units.
Connection
Solder-type
(included with Unit)
Crimp-type
Crimp-type
Note Solder-type connectors are included with each Unit.
We recommend using cable with wire gauges of AWG 28 to AWG 26
2
(0.2 mm to 0.13 mm
max.
1. Check that each Unit is installed securely.
Note Do not apply excessive force on the cables.
2. Cover the Unit while wiring to prevent wire clippings from entering the Unit.
If there is a dustproof label on the top of the Unit, do not remote it before
you wire the Unit. (Remove the label or other covering after wiring has
been completed to allow air circulation needed for cooling.)
Before wiring
3. When solder-type connectors are being used, be sure not to accidentally
short adjacent terminals. Cover the solder joint with heat-shrink tubing.
Pins OMRON set
56 CS1W-CE561 Socket: Fujitsu FCN-361J056-AU
Connector bar: Fujitsu FCN-360C056-J3
56 CS1W-CE562 Socket: Fujitsu FCN-363J056
Connector bar: Fujitsu FCN-360C056-J3
Contacts: Fujitsu FCN-363J-AU
56 CS1W-CE563 Fujitsu FCN-367J056-AU/F
Otax N367J056AUF
2
). Use cable with external wire diameters of 1.61 mm
Section 5-4
Fujitsu/Otax parts
Otax N360C056J3
Otax N363J056
Otax N360C056J3
Otax N363JAU
After wiring
Remove label
after wiring
187
