Specific PLC Setup Settings
Format: Parity
Address in
Programming
Console
Word Bit(s)
144 0 and 1 00: Even
01: Odd
10: None
Default: 00
Baud Rate (bps)
Address in
Programming
Console
Word Bit(s)
145 0 to 7 00 hex: 9,600
01 hex: 300
02 hex: 600
03 hex: 1,200
04 hex: 2,400
05 hex: 4,800
06 hex: 9,600
07 hex: 19,200
08 hex: 38,400
09 hex: 57,600
0A hex: 115,200
(Unit: bps)
Default: 00 hex
Unit Number (for CPU Unit in Host Link Mode)
Address in
Programming
Console
Word Bit(s)
147 0 to 7 00 to 1F hex
(0 to 31)
Default: 00 hex
NT Link Settings
Mode: Communications Mode
Address in
Programming
Console
Word Bit(s)
144 8 to 11 02 hex:1: N NT Link
Default: 00 hex
Settings
These setting is valid only when the commu-
nications mode is set to Host link.
These settings are also valid only when the
Peripheral Port Settings Selection is set to
1: PLC Setup.
Settings
This setting is valid only when the communi-
cations mode is set to the Host Link mode.
These settings are also valid only when the
Peripheral Port Settings Selection is set to
1: PLC Setup.
Settings
This setting determines the CPU Unit's unit
number when it is connected in a 1-to-N
(N=2 to 32) Host Link.
Settings
This setting determines whether the RS-
232C port will operate in host link mode or
another serial communications mode.
Note Communications will not be possible
with PTs set for 1:1 NT Links.
Function
Function
Function
Function
Section 6-2
Related New set-
flags and ting's effec-
words tiveness
A61901 Takes effect
(Peripheral the next
Port Settings cycle.
Changing (Also can be
Flag) changed with
STUP (237).)
Related New set-
flags and ting's effec-
words tiveness
A61901 Takes effect
(Peripheral the next
Port Settings cycle.
Changing (Also can be
Flag) changed with
STUP (237).)
Related New set-
flags and ting's effec-
words tiveness
A61901 Takes effect
(Peripheral the next
Port Settings cycle.
Changing (Also can be
Flag) changed with
STUP (237).)
Related New set-
flags and ting's effec-
words tiveness
A61902 Takes effect
(RS-232C the next
Port Settings cycle.
Changing (Also can be
Flag) changed with
STUP (237).)
