Precautions in Replacing CS1-H PLCs with CS1D PLCs
Item
Instruc- ER Flag operation
tions
and
tasks,
contd
Tasks
Interrupts
Automatic alloca-
tion of communica-
tions ports
Using IORD/IOWR
for CPU Bus Units
Downloading tasks
individually
Function blocks
Function Block
(FB) Function
- Online editing
- Support for in-out
variable (array
specification is
possible for in-out
variable)
- STRING data
(type) and string
processing func-
tion is supported in
Structured Text
Structured Text
can be used in a
task program
SFC language can
be used in a task
program
Multi-interlock
instructions: MILH,
MILR, and MILC
Time comparison
instructions: =DT,
<>DT, <DT, <=DT,
>DT, and >=DT
598
Duplex CPU Systems
The ER Flag will turn ON if
the active and standby CPU
Units cannot be synchronized
for instructions requiring syn-
chronization, including IORF,
DLNK, IORD, IOWR, RXD,
FREAD, FWRIT, and TWRIT.
This does not apply to PID.
Write the program to re-exe-
cute these instructions if the
ER Flag goes ON.
Interrupt tasks are not sup-
ported, but they can be used
as cyclic tasks.
I/O interrupts, scheduled
interrupts, power OFF inter-
rupts, and interrupts from
Inner Boards are not sup-
ported.
Supported in CPU Units with
unit version 1.3 or later.
Not supported.
(Can be used only for Special
I/O Units.)
Not supported.
(The entire program must be
downloaded.)
Supported by the CS1D-
CPU@@HA.
Supported by the CS1D-
CPU@@HA.
Supported by the CS1D-
CPU@@HA.
Supported by the CS1D-
CPU@@HA.
Not supported.
Not supported.
Single CPU Systems
(No precautions in converting from
the CS1-H.)
No precautions in converting from
the CS1-H.
No precautions in converting from
the CS1-H.
No precautions in converting from
the CS1-H.
No precautions in converting from
the CS1-H.
No precautions in converting from
the CS1-H.
Supported by the CS1D-CPU@@HS. Supported.
Supported by the CS1D-CPU@@SA. Supported.
Supported by the CS1D-CPU@@SA. Supported
Supported by the CS1D-CPU@@SA. Supported
No precautions in converting from
the CS1-H.
No precautions in converting from
the CS1-H.
Appendix E
CS1-H (See note.)
---
Interrupt tasks are
supported.
I/O interrupts,
scheduled inter-
rupts, power OFF
interrupts, and inter-
rupts from Inner
Boards are sup-
ported.
Supported.
Supported.
Supported, but only
in PROGRAM
mode.
Supported.
Supported.
