Omron SYSMAC CS1D-PD Series Operation Manual page 118

Programming Devices
CX-Programmer
Connections
Personal computer
IBM PC/AT or com-
patible
CS1W-CN118
CS1W-CN226
CS1W-CN616
(See note 1.)
Note
78
There are differences in functions depending on the version of CX-Program-
mer connected to the CS1D PLC. These are listed in the following table.
CX- Duplex CPU
Programmer
Version 2.@ or Not sup-
lower ported.
Version 3.@ Supported.
Version 4.@ or Supported.
higher
For the main specifications of CX-Programmer, refer to the manual of
your CX-Programmer.
Peripheral port connection
9-pin male
DUPLEX
Peripheral port
9-pin
10-pin female
female
CS1W-CN118 (0.1 m) (See note 1.)
CS1W-CN226 (2.0 m)
CS1W-CN616 (6.0 m)
9-pin
female
1. The CS1W-CN118 Cable is used with one of the RS-232C Cables shown
on the right (XW2Z-@@@S-@@) to connect to the peripheral port on the
CPU Unit.
RS-232C Cable
Single CPU
Systems Systems
Not sup-
ported.
Not sup-
ported.
Supported.
RS-232C port connection
9-pin male
XW2Z-200S-CV/200S-V (See note 2.)
XW2Z-500S-CV/500S-V (See note 2.)
XW2Z-200S-
CV/200S-V or
XW2Z-500S-
10-pin
CV/500S-V
DUPLEX
CS1W-CN118
Section 2-6
Remarks
This version cannot be used for
CS1D PLCs.
Online Unit replacement is supported
for version 3.1 or higher.
Select "CS1H-H" as the device type.
When using duplex functions, select
Duplex Settings from the Option
Menu in the PLC Setup.
Not supported in CS1D-CPU@@HA.
Single CPU Systems are not sup-
ported.
Select "CS1D-S" as the device type
when using a Single CPU System.
In CS1D-CPU@@H, select the PLC
model "CS1D-H."
The "CS1H-H" can also be selected
as the device type, but if it is, then
Duplex Settings must be selected
from the Option Menu in the PLC
Setup.
Supported if the PLC model: "CS1D-
H" is selected in CS1D-CPU@@HA.
Note CS1D-CPU@@HA requires
Ver. 9.7 or later.
DUPLEX
9-pin
male
9-pin
RS-232C port
female
9-pin female
9-pin 9-pin
female male
Peripheral port
