Online Replacement of I/O Units, Special I/O Units, and CPU Bus Units
Unit Types
Note
460
Word Bits
A040 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 6. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A041 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 7. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A261 10 ON while an online replacement operation is in progress. Turns
OFF when the operation is completed normally.
The unit types displayed on the Programming Console during online replace-
ment are listed in the following table.
Unit
None or Dummy Unit
Basic I/O Input Unit
Units
Output Unit
Mixed I/O Unit
Interrupt Input
Unit
Special I/O Unit
CPU Bus Ethernet Unit
Units
CS1D Ethernet
Unit
Controller Link
Unit
SYSMAC Link
Unit
Serial Communi-
cations Unit
DeviceNet Unit
Loop Control Unit "LC" followed by the unit
1. If a Duplex Controller Link Unit is used, "a" will be added to the end of the
display for the active Unit and "s" will be added for the standby Unit. For
example, "NS12a" would be a Controller Link Unit with a unit number of 12
functioning as the active Unit. "NS12s" would be the same Unit functioning
as the standby Unit.
2. When using duplex Ethernet Units (CS1D Ethernet Units), a "p" will be
added to the end of the unit type for the primary Unit and an "s" will be add-
ed for the secondary Unit.
Examples:
ED10p: The primary CS1D Ethernet Unit set to unit number 10
ED10s: The second CS1D Ethernet Unit set to unit number 10
Description
Programming Console
display
*****
"I" followed by number of
input points
"O" followed by number of
output points
"M" followed by number of
I/O points
"INT" followed by the Inter-
rupt Input Unit number.
(Interrupt Input Units can
be used only as normal
Input Units for the CS1D.)
"SIO" followed by the unit
number
"ET" followed by the unit
number
"ED" followed by the unit
number
"NS" followed by the unit
number
"SL" followed by the unit
number
"SC" followed by the unit
number
"DN" followed by the unit
number
number
Section 11-4
Examples
*****
I8, I16, I32, I48, I64, I96
O8, O16, O32, O48, O64,
O96
M8, M16, M32, M48,
M64, M96
INT0, INT1
SIO00, SIO95
ET00
ED10 (See note 2.)
NS12 (See note 1.)
SL11
SC13
DN14
LC15
