Online Replacement of I/O Units, Special I/O Units, and CPU Bus Units
Canceling Online
Replacement
Related Auxiliary Area Flags
Use the following procedure to return to the initial display after starting the
online replacement procedure.
• Instead of the Rack and slot numbers, press the following keys to enter
Online Replacement Mode.
FUN SHIFT
• Press the INS Key and Down Key to go to the display that appears for
step 6. This will enable ending the online replacement operation.
Word Bits
A034 00 to 04 Used to confirm when online replacement is in progress for a slot
on Rack 0. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 04 correspond to
slots 0 to 4.
00: ON when online replacement is in progress for slot 0 on Rack
0.
01: ON when online replacement is in progress for slot 1 on Rack
0.
02: ON when online replacement is in progress for slot 2 on Rack
0.
03: ON when online replacement is in progress for slot 3 on Rack
0.
04: ON when online replacement is in progress for slot 4 on Rack
0.
A035 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 1. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A036 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 2. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A037 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 3. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A038 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 4. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
A039 00 to 08 Used to confirm when online replacement is in progress for a slot
on Rack 5. A bit will be ON when online replacement is in
progress for the corresponding slot. Bits 00 to 08 correspond to
slots 0 to 8.
Replace End
↓
5-8=I32
Replace?
CLR
?-?=
*EM
CH
*DM
EM_/EXT
Replace End?
INS
~5-8=I32
Replace End
↓
5-8=I32
Description
Section 11-4
