Specifications
Function
Multiple-level commu- Duplex CPU Systems: 3 levels
nications Single CPU Systems: 8 levels
Note Communications are possible across up to eight
Storing comments in I/O comments can be stored in the Memory Card or EM file
CPU Unit memory, or in the comment memory in the CPU Unit flash
memory (unit version 4.0 or later).
Program check Program checks are performed at the beginning of opera-
tion for items such as no END instruction and instruction
errors.
CX-Programmer can also be used to check programs.
Control output signals RUN output: An internal contact turns ON when the CPU
Unit is operating in RUN or MONITOR mode.
These terminals are provided only on CS1D-PA207R
Power Supply Units.
Battery service life Battery Set: CS1W-BAT01
Self-diagnostics CPU errors (watchdog timer), I/O verification errors, I/O bus
errors, memory errors, and battery errors
Other functions Storage of number of times power has been interrupted.
(Stored in A514.)
2-1-4 General Specifications
Item
CS1D Power Supply Unit
Power supply voltage
Operating voltage range
Power consumption
Inrush current
Power supply output capacity
Power supply output terminal
Specifications
levels only for the Controller Link and Ethernet net-
works (and the CX-Integrator or CX-Net in CX-Pro-
grammer version 4.0 or higher is required to set the
routing tables). Communications are possible
across only up to three communications levels for
the SYSMAC LINK, DeviceNet, and FL-net net-
works.
CS1D-PA207R
100 to 120 V AC/200 to
240 V, 50/60 Hz
85 to 132 V AC/170 to
264 V
150 VA max.
100 to 120 V AC: 30 A
max. (cold start at normal
temperatures); 8 ms max.
200 to 240 V AC: 40 A
max. (cold start at normal
temperatures); 8 ms max.
(See note 1.)
5 V DC, 7 A (including the
CPU Unit power supply)
26 V DC, 1.3 A
Total: 35 W max.
Not provided.
---
I/O comments: CX-Programmer
User Manual
Storing comments in CPU Units:
Programming Manual (W394)
Programming Manual (W394)
Programming Manual (W394)
11-2-1 Battery Replacement
10-2-4 Errors and Troubleshooting
9-3 Power OFF Operation
Specifications
CS1D-PD024
24 V DC
19.2 to 28.8 V DC
40 W max.
30 A max.
5 V DC, 4.3 A (including the
CPU Unit power supply)
26 V DC, 0.56 A
Total: 28 W max.
Not provided.
Section 2-1
Reference
CS1D-PD025
24 V DC
19.2 to 28.8 V DC
60 W max.
30 A max.
5 V DC, 5.3 A (including the
CPU Unit power supply)
26 V DC, 1.3 A
Total: 40 W max.
Not provided.
