Auxiliary Area Allocations
Address Name
Words Bits
A050 A05000 Basic I/O
to Unit Infor-
A05007 mation,
Rack 0
Slot 0
A05008 Basic I/O
to Unit Infor-
A05015 mation,
Rack 0
Slot 1
A051 to A05100 Basic I/O
A089 to Unit Infor-
A08915 mation,
Racks 2 to
7
A090 to --- User Pro-
A093 gram Date
A094 to --- Parameter
A097 Date
Function
A bit will turn ON to indicate when a
fuse has blows. The bit numbers
correspond to the fuse number on
the Unit.
These words contain in BCD the
date and time that the user program
was last overwritten.
A09000 to A09007:
Seconds (00 to 59)
A09008 to A09015:
Minutes (00 to 59)
A09100 to A09107: Hour (00 to 23)
A09108 to A09115:
Day of month (01 to 31)
A09200 to A09207: Month (01 to 12)
A09208 to A09215: Year (00 to 99)
A09308 to A09307: Day of the week
(00: Sunday, 01: Monday, 02: Tues-
day, 03: Wednesday, 04: Thursday,
05: Friday, 06: Saturday)
These words contain in BCD the
date and time that the parameters
were last overwritten.
The format is the same as above.
Settings Status
after
mode
change
ON: Fuse blown ---
OFF: Normal
---
---
--- Held
--- Held
Appendix B
Status at Timing Related
startup flags,
settings
--- Every ---
cycle
--- ---
--- ---
Held --- ---
Held --- ---
