Omron SYSMAC CS1D-PD Series Operation Manual page 143

Basic I/O Units
Components and Switch Settings
CS-series Basic Input Units (20-pin Terminal Block)
16-point Unit
CS
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
8-point Unit
CS
0 1 2 3 4 5 6 7
Dimensions
CS-series Basic I/O Units (20-pin Terminal Blocks)
CS1W-IA111
CS1W-IA211
CS1W-ID211
CS1W-INT01
CS1W-IDP01
CS1W-OD211
CS1W-OD212
CS1W-OA201
CS1W-OA211
CS1W-OC201
CS1W-OC211
I/O indicator
Terminal block
connector
(20-pin)
20-pin terminal block
CS1W-ID211
CS1W-INT01
CS1W-IDP01
CS1W-OD211
CS1W-IA111
CS1W-IA211
CS1W-OC211
CS1W-OA211
CS1W-OC201
CS
130
35
Terminal Dimensions
6.6
8.4
Unit mounting hooks
Hooked onto Back-
plane to mount Unit.
Model label
16-point Units
CS
with ERR indica-
ER R
0 1 2 3 4 5 6 7
tor (load short-cir-
8 9 10 11 12 13 14 15
cuit)
8-point Units
CS
with ERR indica-
ER R
0 1 2 3 4 5 6 7
tor (fuse burnout)
124
147
M3.5
7.2
Section 2-11
CS1W-OD212
CS1W-OA201
103
