Omron SYSMAC CS1D-PD Series Operation Manual page 208

Installation
Phillips
screwdriver
5-2-6 I/O Connecting Cables
Type
CS-series I/O Connecting Cables CS1D-CN@@3 Simple lock
CV-series Long-distance Expan-
sion Rack I/O Connecting Cables
Model Numbers
168
Duct
20 mm min.
Unit
Backplane
20 mm min.
Duct
4. To remove a Unit, use a phillips-head screwdriver to loosen the screw at
the bottom of the Unit, rotate the Unit upward, and remove it.
I/O Connecting Cables are used to connect the CPU Rack and Expansion
Racks. There are two types of I/O Connecting Cables.
Model number
CPU Rack
connector
CV500- Simple lock connector
CN@@2
CS-series I/O Connecting Cables
Model number
CS1W-CN313 (See note.)
CS1W-CN713 (See note.)
CS1W-CN223
CS1W-CN323
CS1W-CN523
CS1W-CN133
CS1W-CN133B2
Connectors
Expansion Rack
CPU Rack →
Simple lock con-
nector Expansion Rack
Expansion Rack →
Expansion Rack
CPU Rack or Expansion Rack
→
Long-distance Expansion Rack
Cable length
0.3 m
0.7 m
2 m
3 m
5 m
10 m
12 m
Section 5-2
Usage
