Omron SYSMAC CS1D-PD Series Operation Manual page 658

CJ1W-CIF11 RS-422A Converter
Wiring for Two-wire Cable
DIP Switch Settings
Terminating resistance
Two-wire/four-wire
Two-wire/four-wire
Not used.
RD control
SD control
618
CS1D CPU Unit CS1D CPU Unit
(master) (slave 0)
ON (with)
ON (two-wire)
ON (two-wire)
OFF
OFF (without)
ON (with)
OFF (without)
ON (two-wire)
ON (two-wire)
OFF
OFF (without)
ON (with)
Appendix G
CS1D CPU Unit
(slave 1)
ON (with)
ON (two-wire)
ON (two-wire)
OFF
OFF (without)
ON (with)
