Omron SYSMAC CS1D-PD Series Operation Manual page 246

Specific PLC Setup Settings
Data Shift Process Instructions
Address in
Programming
Console
Word Bit(s)
198 13 0: Not executed in
background
1: Executed in back-
ground
Default: 0
Communications Port Number for Background Execution
Address in
Programming
Console
Word Bit(s)
198 0 to 3 0 to 7: Communica-
tions ports 0 to 7
(internal logical
ports)
FB Communications Instruction Settings (CS1D-CPU@@HA/SA only)
Programming
Console address
Word Bit(s)
+ 200 0 to 3 0 to F: 0 to 15
Default: 0
Programming
Console address
Word Bit(s)
+ 201 0 to 15 0001 to FFFF (Unit:
0.1 s, 0.1 to 6553.5)
0000: 2 s
206
Settings
This setting determines if Data Shift Instruc-
tions will be processed over multiple cycle
times (i.e., processed in the background).
Note This setting cannot be used with Duplex CPU Systems.
Settings
The communications port number (internal
logical port) that will be used for background
execution.
Note This setting cannot be used with Duplex CPU Systems.
The following PLC Setup settings are used only when using the OMRON FB
Library.
Number of Resends
■
Settings
Set the number of retries for sending com-
mands when executing DeviceNet explicit
messages or FINS messages within func-
tion blocks.
FB Communications Instruction Response Monitoring Time
■
Settings
A response timeout occurs when no
response is returned within the time set here
for FINS commands executed within a func-
tion block.
Function
Function
Function
Function
Section 6-2
Related New set-
flags and ting's effec-
words tiveness
--- Start of oper-
ation
Related New set-
flags and ting's effec-
words tiveness
--- Start of oper-
ation
Related New set-
flags and ting's effec-
words tiveness
A58000 to Start of
A58003
operation
Related New set-
flags and ting's effec-
words tiveness
A581 Start of
operation
