Omron SYSMAC CS1D-PD Series Operation Manual page 346

Auxiliary Area
Name
Instruction Processing Error
Flag
Indirect DM/EM BCD Error
Flag
Illegal Access Error Flag
No END Error Flag
Task Error Flag
Differentiation Overflow Error
Flag
Illegal Instruction Error Flag
UM Overflow Error Flag
Program Address Where Pro-
gram Stopped
Error Information
Error Log, Error Code
■
Name
Error Log Area
Error Log Pointer
Error Log Pointer Reset Bit
Error Code
306
Address
A29508 This flag and the Error Flag (ER) will be turned ON when an
instruction processing error has occurred and the PLC
Setup has been set to stop operation for an instruction error.
A29509 This flag and the Access Error Flag (AER) will be turned ON
when an indirect DM/EM BCD error has occurred and the
PLC Setup has been set to stop operation an indirect DM/
EM BCD error.
A29510 This flag and the Access Error Flag (AER) will be turned ON
when an illegal access error has occurred and the PLC
Setup has been set to stop operation an illegal access error.
A29511 ON when there isn't an END(001) instruction in each pro-
gram within a task.
A29512 ON when a task error has occurred. The following conditions
will generate a task error.
1) There isn't an executable cyclic task.
2) There isn't a program allocated to the task.
A29513 ON when the specified Differentiation Flag Number exceeds
the allowed value.
A29514 ON when a program that cannot be executed has been
stored.
A29515 ON when the last address in UM (user program memory)
has been exceeded.
A298 and These words contain the 8-digit hexadecimal program
A299 address of the instruction where program execution was
stopped due to a program error.
(A299 contains the leftmost digits.)
Address
A100 to When an error has occurred, the error code, error contents,
A199 and error's time and date are stored in the Error Log Area.
A300 When an error occurs, the Error Log Pointer is incremented
by 1 to indicate the location where the next error record will
be recorded as an offset from the beginning of the Error Log
Area (A100).
A50014 Turn this bit ON to reset the Error Log Pointer (A300) to 00. Read/write
A400 When a non-fatal error (user-defined FALS(006) or system
error) or a fatal error (user-defined FALS(007) or system
error) occurs, the 4-digit hexadecimal error code is written to
this word.
Description
Description
Section 8-11
Access
Read-only
Read-only
Read-only
Read-only
Read-only
Read-only
Read-only
Read-only
Read-only
Access
Read-only
Read-only
Read-only
