Duplex Unit
Duplex Unit Operating
Switch
Duplex Setting Switches
52
DPL
USE
NO USE
Setting
USE Turns ON power to
the Duplex Unit.
NO USE Turns OFF power to
the Duplex Unit.
DPL SW
ON
SPL
ACT.
LEFT
ON
(1) Mode Setting Switch (DPL/SPL)
Switch Setting
DPL/SPL OFF DPL Duplex
ON SPL Sim-
Note Duplex Mode and Simplex Mode can also be determined by the status of bit
08 of word A328.
(2) Active Setting Switch (ACT. RIGHT/ACT. LEFT)
Switch
ACT OFF ACT
RIGHT/ RIGHT
ACT
LEFT
ON ACT
LEFT
Contents
Turns ON or OFF the
power supply to the
Duplex Unit.
OFF
DPL
ACT.
RIGHT
Meaning
Sets whether the System will
Mode operate in Duplex Mode or Sim-
plex Mode.
This switch is enabled in the fol-
plex
lowing situations:
Mode
1) When the power is turned ON.
2) When the CPU Operation Set-
ting Switch is switched from NO
USE to USE.
3) When the Initial Switch is
pressed.
Note: Switching is disabled dur-
ing operation. This switch is also
disabled in a Simplex System.
Setting
Sets the right Sets whether the right
CS1D CPU Unit or left CS1D CPU Unit
as the active is to be the active Unit.
Unit.
This switch is enabled
only when the power
Sets the left
is turned ON, so, after
CS1D CPU Unit
changing the setting,
as the active
turn the power OFF
Unit.
and then back ON
again.
Changing the setting
is disabled during
operation. This switch
is also disabled in
Simplex Mode.
Section 2-3
Application
Set to NO USE when
replacing a Duplex Unit.
while leaving the power
ON.
The Duplex CPU System
will operate in Simplex
Mode during replace-
ment.
Application
Set to OFF
(DPL) for Duplex
Mode, and to
ON (SPL) for
Simplex Mode.
Contents Application
To set the right
CS1D CPU Unit
as the active
Unit, set the
switch to OFF
(ACT RIGHT).
To set the left
CS1D CPU Unit
as the active
Unit, set the
switch to ON
(ACT LEFT).
