Precautions in Replacing CS1-H PLCs with CS1D PLCs
Observe the following precautions when replacing a CS1-H system (see note) with a CS1D system, and make
sure the new system is suitable for the application conditions.
Note The information in the following table is based on CS1-H CPU Unit Ver. 4.1. Refer to the CS Series PLC
Operation Manual (W339) for differences between unit versions.
Item
Units CPU Unit
Power Supply Unit CS1D Power Supply Units
CPU Backplane
Expansion Back-
plane
Appendix E
Duplex CPU Systems
CPU Units for Duplex CPU
Systems required.
CS1D-CPU@@H
When using FB/ST/SFC, use
the CS1D-CPU@@HA.
required.
CS1D-PA/PD@@@@
CPU Backplanes for Duplex
CPU Systems required.
• Duplex CPU, Dual I/O
Expansion Systems:
CS1D-042D
• Duplex CPU, Single I/O
Expansion Systems:
CS1D-BC052
CS1D Expansion Backplane
required.
• Duplex CPU, Dual I/O
Expansion Systems:
CS1D-BI082D
• Duplex CPU, Single I/O
Expansion Systems:
CS1D-BI092
Single CPU Systems
CPU Units for Single CPU Systems
required.
CS1D-CPU@@S
When using FB/ST/SFC, use the
CS1D-CPU@@SA.
CS1D Power Supply Units required.
CS1D-PA/PD@@@@
CPU Backplanes for Duplex CPU
Systems required.
CS1D-BC082S
CS1D Expansion Backplane
required.
CS1D-BI092
CS1-H (See note.)
CS1-H CPU Units
required.
CS1G/H-CPU@@H
C200HW Power
Supply Units
required.
C200HW-PA/
PD@@@@
CS1W CPU Back-
planes required.
CS1W-BC@@3
CS1W-BC@@2
CS1D or C200H
Expansion Back-
plane required.
CS1W-BI@@3
CS1W-BI@@2
C200HW-BI@@1(-
V1)
