Unit Settings Tab Page - Omron SYSMAC CS1D-PD Series Operation Manual

Specific PLC Setup Settings
6-2-5

Unit Settings Tab Page

Basic I/O Unit Input (Rack) Response Times
Item
Rack 0, Slot 0 10
Rack 0, Slot 1
Rack 0, Slot 2 11
Rack 0, Slot 3
Rack 0, Slot 4 12
Rack 0, Slot 5
Rack 0, Slot 6 13
Rack 0, Slot 7
Rack 0, Slot 8 14
Rack 0, Slot 9
Rack 1, Slots 0 to 9 15 to 19 See
Rack 2, Slots 0 to 9 20 to 24
Rack 3, Slots 0 to 9 25 to 29
Rack 4, Slots 0 to 9 30 to 34
Rack 5, Slots 0 to 9 35 to 39
Rack 6, Slots 0 to 9 40 to 44
Rack 7, Slots 0 to 9 45 to 49
210
Address in Settings
Programming
Console
Word Bit(s)
0 to 7 00 hex: 8 ms
10 hex: 0 ms
8 to 15
11 hex: 0.5 ms
0 to 7
12 hex: 1 ms
13 hex: 2 ms
8 to 15
14 hex: 4 ms
0 to 7
15 hex: 8 ms
8 to 15
16 hex: 16 ms
17 hex: 32 ms
0 to 7
Default:
8 to 15
00 hex (8 ms)
0 to 7
8 to 15
Rack 0.
Function
Sets the input response time
(ON response time = OFF
response time) for CS-series
Basic I/O Units. The default
setting is 8 ms and the setting
range is 0.5 ms to 32 ms.
This value can be increased to
reduce the effects of chatter-
ing and noise, or it can be
reduced to allow reception of
shorter input pulses.
Section 6-2
Related New set-
flags and ting's
words effective-
ness
A220 to At startup
A259:
Actual
input
response
times for
Basic I/O
Units
