VLT® Refrigeration Drive FC 103
Operating Guide
FC 102
Sine-wave filter overtemperature trip [°C
(°F)]
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
1
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-efficiency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficiency
2
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
3 See also Input Power Option Losses section.
If using an output filter, the output frequency is limited further. See the Motor Output (U, V, W) section.
4

10.2 Mains Supply

The unit is suitable for use on a circuit capable of delivering not more than 65 kA short circuit current rating (SCCR) at 480/600 V.
Supply terminals
Supply voltage
(1)
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (cos Φ)
Switching on the input supply L1, L2, and L3 (power-ups)
Environment according to EN 60664-1
Mains voltage low/mains drop-out: During low mains voltage or a mains drop-out, the drive continues until the DC-link voltage drops below the
1
minimum stop level, which corresponds typically to 15% below the drive's lowest rated supply voltage. Power-up and full torque cannot be expec-
ted at mains voltage lower than 10% below the drive's lowest rated supply voltage.
Calculations based on UL/IEC 61800-3.
2

10.3 Motor Output and Motor Data

10.3.1 Motor Output (U, V, W)

Output voltage
Output frequency (without sine-wave filter)
Output frequency (with sine-wave filter and no derating)
Output frequency (with sine-wave filter and derating)
Output frequency in flux mode
Switching on output
Ramp times
Dependent on voltage and power.
1

10.3.2 Torque Characteristics

Starting torque (constant torque)
Starting/overload torque (variable torque)
Torque rise time in flux (for 5 kHz f
Danfoss A/S © 2020.09
N500
150 (302)
)
sw
N560 N630
150 (302) 150 (302)
Overvoltage category III/pollution degree 2
Maximum 150% for 60 s once in 10 minutes
Maximum 110% up to 0.5 s once in 10 minutes
Specifications
N710 N800
150 (302) 150 (302)
380–480/500 V ±10%, 525–690 V ±10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥0.9 nominal at rated load
Near unity (>0.98)
Maximum 1 time/2 minutes
0–100% of supply voltage
0–60 Hz without derating
AQ357954340588en-000201 / 130R0881 | 147
L1, L2, L3
(2)
0–590 Hz
(1)
0–100 Hz
0–300 Hz
Unlimited
0.01–3600 s
(1)
(1)
1 ms
