VLT® AQUA Drive FC 202
Design Guide
Displacement power factor (cos Φ)
Switching on the input supply L1, L2, L3 (power-ups) ≤7.5 kW
Switching on input supply L1, L2, L3 (power-ups) 11–90 kW
Environment according to EN60664-1
Mains voltage low/mains drop-out: During low mains voltage or a mains drop-out, the drive continues until the DC-link voltage drops below the
1
minimum stop level, which corresponds typically to 15% below the drive's lowest rated supply voltage. Power-up and full torque cannot be exptec-
ted at mains voltage lower than 10% below the drive's lowest rated supply voltage.
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 240/500/600/690 V maximum.
2
The drive power supply is tested in accordance with IEC 61000-4-28, 50 Hz +4/-6%.
3

8.3 Motor Output and Motor Data

8.3.1 Motor Output (U, V, W)

Output voltage
Output frequency
Switching on output
Ramp times
Dependent on power size.
1

8.3.2 Torque Characteristics, Normal Overload

Starting torque (constant torque)
Overload torque (constant torque)
1 Percentage relates to the nominal torque of the drive, dependent on power size.

8.3.3 Torque Characteristics, High Overload

Starting torque (constant torque)
Overload torque (constant torque)
Percentage relates to the nominal torque of the drive, dependent on power size.
1

8.4 Ambient Conditions

8.4.1 Environment

Enclosure size A
Enclosure sizes B1/B2
Enclosure sizes B3/B4
Enclosure sizes C1/C2
Enclosure sizes C3/C4
Enclosure kit available ≤ enclosure size A
Vibration test enclosure A/B/C
Maximum relative humidty
Aggressive environment (IEC 60068-2-43), uncoated
Aggressive environment (IEC 60068-2-43), coated
Test method according to IEC 60068-2-43
Ambient temperature (at SFAVM switching mode)
- with derating
90 | Danfoss A/S © 2020.09
Overvoltage category III/pollution degree 2
Maximum 110% for 60 s, once in 10 minutes
Maximum 110% for 60 s, once in 10 minutes
Maximum 150/160% for 60 s, once in 10 minutes
Maximum 150/160% for 60 s, once in 10 minutes
IP20/Chassis, IP21/Type 1, IP55/Type 12, IP66/Type 4X
IP21/Type 1, IP55/Type 12, IP66/Type 4X
IP21/Type 1, IP55/Type 12, IP66/Type 4X
5–95% (IEC 721-3-3); Class 3K3 (non-condensing) during opera-
AJ300847815559en-000101 / 130R0337
Specifications
Near unity (>0.98)
Maximum 2 times per minute
Maximum 1 time per minute
0–100% of supply voltage
0–590 Hz
(1)
Unlimited
1–3600 s
(1)
(1)
(1)
(1)
IP20/Chassis
IP20/Chassis
IP21/TYPE 1/IP4X top
1.0 g
tion
Class 3C2
Class 3C3
H2S (10 days)
Maximum 55° C (131° F)
(1)
