INVT Goodrive300 Series Operation Manual page 67

Goodrive300 Series VFD
Function
Name
code
vector control 2: AI2
Upper
frequency of
P03.15 reverse
rotation in
vector control
Keypad
setting for
upper
P03.16
frequency of
forward
rotation
Keypad
setting for
upper
P03.17
frequency of
reverse
rotation
Upper
electromotion
P03.18
torque
source
Upper braking
torque
P03.19
source
Detailed instruction of parameters
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication setting upper-limit
frequency
7: PROFIBUS\CANopen communication setting
upper-limit frequency
8: Ethernet communication setting upper-limit
frequency
9: Reserved
Note: For setting
corresponds to the maximum frequency.
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
This function code is used to select the
electromotion and braking torque upper-limit
setting source selection.
0: Keypad setting upper-limit frequency(P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
62
modes of 1–9,
Function parameters
Default
Modify
value
0
○
100%
50.00
○
Hz
50.00
○
Hz
0
○
0
○
