Goodrive300 Series VFD
Function
code
Speed control
P00.00
Torque setting
P03.11
Keypad setting
P03.12
Torque reference
P03.13
Upper frequency of
P03.14 forward rotation in
vector control
Upper frequency of
P03.15 reverse rotation in
vector control
Name
0: Sensorless vector control mode 0 (applicable
to AM and SM)
1: Sensorless vector control mode 1 (applicable
mode to AM)
2: SVPWM control mode (applicable to AM and
SM)
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
method 6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS\CANopen communication setting
torque
9: Ethernet communication setting torque
10: Reserved
-300.0%–300.0%
torque (rated current of the motor)
0.000–10.000s
filter time
0: Keypad (P03.16 sets P03.14, P03.17 sets
P03.15)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication setting upper-limit
frequency
7: PROFIBUS/CANopen communication setting
upper-limit frequency
8: Ethernet communication setting upper-limit
frequency
Detailed instruction of parameters
140
Basic operation instruction
Default
value
1
0
50.0%
0.010s
0
0
