INVT Goodrive300 Series Operation Manual page 198

Goodrive300 Series VFD
Code Fault
fault
PROFIBUS
E-DP communication
fault
Ethernet
E-NET communication
fault
CANopen
E-CAN communication
fault
Grounding
ETH1
shortcut fault 1
Grounding
ETH2
shortcut fault 2
Cause
The keypad wire is too long
and affected by
interference.
There is mistake on the data
storage of the keypad.
Communication address is not
correct.
Corresponding resistor is not
dialed
The files of main stop GSD
does not set sound
The peripheral interference is
too large.
The Ethernet address is not
set right.
The Ethernet communication
is not selected to right.
The peripheral interference is
too large.
The connection is not sound
Corresponding resistor is not
dialed
The communication baud rate
is not matched
The peripheral interference is
too large.
The output of the VFD is short
circuited with the ground.
There is fault in the current
detection circuit.
The actual motor
sharply differs from the VFD
power.
The output of the VFD is short
circuited with the ground.
There is fault in the current
detection circuit.
The actual motor
sharply differs from the VFD
193
Change the hardware and ask for
strong service.
Repack-up the data in the keypad.
Check related setting
Check
environment,
interference effects.
Check the related setting.
Check the communication method
selection.
Check
environment,
interference effects.
Check the connection
Draw out the correspond resistor
Set the same baud rate
Check
environment,
interference effects.
Check if the connection of the
motor is normal or not
Change the hall
power Change the main control panel
Set motor parameters correctly.
Check if the connection of the
motor is normal or not
Change the Hall
Change the main control panel
power
Set motor parameters correctly.
Fault tracking
Solution
the surrounding
and eliminate
the surrounding
and eliminate
the surrounding
and eliminate
