Goodrive300 Series VFD
Function
Name
code
Polarity
selection of
P05.10
the input
terminals
ON-OFF filter
P05.11
time
Virtual
P05.12
terminals
setting
Detailed instruction of parameters
temporarily
34: DC brake
35: Shift the motor 1 into motor 2
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Comsumption power clear
41: Comsumption power holding
42–60: Reserved
61: PID pole switching
62–63: Reserved
The function code is used to set the polarity of the
input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT0
BIT1
S1
S2
BIT5
BIT6
S6
S7
Setting range: 0x000–0x1FF
Set the sample filter time of S1–S8 and HDI
terminals. If the interference is strong, increase
the parameter to avoid the disoperation.
0.000–1.000s
0x000–0x1FF(0: Disabled, 1: Enabled)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
Note: After a virtual terminal is enabled, the state
of the terminal can only be modified through
71
BIT2
BIT3
BIT4
S3
S4
BIT7
BIT8
S8
HDI
Function parameters
Default
Modify
value
0x000
S5
0.010s
0x000
