INVT Goodrive300 Series Operation Manual page 69

Goodrive300 Series VFD
Function
Name
code
time
Weak
magnetic
P03.26
proportional
gain
Vector control
P03.27
speed
Compensation
P03.28 coefficient of
static friction
Compensation
coefficient of
P03.29
dynamic
friction
P04 Group SVPWM control
Motor 1V/F
P04.00
curve setting
Detailed instruction of parameters
Build up a magnetic field inside the VFD to
improve the torque performance during the
starting process.
The setting time: 0.000–10.000s
0–8000
Note: P03.24–P03.26 are invalid for the vector
mode.
0: Display the actual value
1: Display the setting value
0.0–100.0%
Adjust P03.28 to compensate the coefficient of
static friction. Only valid when setting in 1Hz.
0.0–100.0%
Adjust P03.29 to compensate the coefficient of
static friction. Only valid when setting in 1Hz.
These function codes define the V/F curve of
Goodrive300 motor 1 to meet the need of
different loads.
0: Straight line V/F curve； applying to the constant
torque load
1: Multi-dots V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
Curves 2–4 apply to the torque loads such as
fans and water pumps. Users can adjust
according to the features of the loads to achieve a
best energy-consuming effect.
5: Customized V/F(V/F separation); on this mode,
V and F can be separated from adjusted through
the frequency given channel set by P00.06 or the
voltage given channel set by P04.27 to change
64
Function parameters
Default
Modify
value
1000
○
0
○
0.0%
○
0.0%
○
0
◎
