INVT Goodrive300 Series Operation Manual page 120

Goodrive300 Series VFD
Function
Name
code
source current
Original pole
P13.01
test mode
Source current
P13.02
Source current
P13.03
Shift
P13.04 frequency of
source current
Superposing
P13.05 frequency
(reserved)
Pulse
P13.06 superposing
voltage
P13.07 Reserved
Control
P13.08
parameter 1
Control
P13.09
parameter 2
P13.10 Reserved
Maladjustment
P13.11
detection time
High
P13.12
frequency
Detailed instruction of parameters
0: No test
1: High-frequency superposition (reserved)
2: Pulse superposition
Source current is the positioning current of the
magnetic pole position. Source current 1 is valid
under the frequency point of current shifting.
1 Increasing the value can raise the starting torque.
Setting range: 0.0%–100.0% (rated current of the
motor)
Source current is directional current of the
magnetic pole position. Source current 2 is valid
under the frequency point of current shifting.
2 There is no need to modify the value generally.
Setting range: 0.0%–100.0% (rated current of the
motor)
Valid frequency shifting point between source
current 1 and current 2.
Setting range: 0.00Hz–P00.03 (Max. frequency)
200–1000Hz
0.0–300.0% (rated voltage of the motor)
0–65535
0–65535
0–655.35
0–65535
Adjust the response of anti-maladjustment.
Bigger load inertia may increase the value, but
the response will be slower.
Setting range: 0.0–10.0s
When the motor speed is faster than the rated
speed, the parameter is valid, if vibration occurs
115
Function parameters
Default
Modify
value
0
◎
20.0% ○
10.0%
○
10.00
○
Hz
500Hz
◎
40.0%
◎
0
○
0
○
2.00
○
0
○
0.5s ○
0.0%
○
