Goodrive300 Series VFD
4.2.4 Installation of one VFD
A
Note: The minimum space of B and C is 100 mm.
4.2.5 Installation of multiple VFDs
A
B
A
Note:
Before installing the different sizes VFDs, please align their top position for the convenience of
later maintenance.
The minimum space of B, D and C is 100 mm.
A
B
B
Figure 4-3 Stand-alone installation
D
Figure 4-4 Parallel installation
Warm air
B
19
Installation guide
C
C
Cool air
Warm air
Cool air
C
C
