EC-TX-103 communication cards). In order to use PROFIBUS/CANOPEN control VFD, the
communication module must be set to be VFD controller.
Actual value: Actual value is a 16-bit word, which contains converter operation information. Monitoring
capabilities are defined by VFD parameter. The integer scaling of actual value is sent to master
machine depending on selected function, please refer to VFD manual.
Note: VFD always check the control word (CW) and bytes of given value.
Mission message (From master station to VFD)
Control word (CW): The first word of PZD is control word (CW) of VFD. The definitions of CWs on the
PWM rectifier regenerative part are different from those on the inverter part, and therefore two tables
are used to describe the CWs.
Control word (CW) of Goodrive300 series
Bit
COMMAND BYTE
0–7
8 WIRTE ENABLE
9–10 MOTOR GROUP SELECTION
TORQUE CONTROL
11
SELECTION
ELECTRIC CONSUMPTION
12
13 PRE-EXCIATION
14 DC BRAKE
15 HEARTBEAT REF
Name
CLEAR
Value
1 Forward running
2 Reverse running
3 Forward jogging
4 Reverse jogging
5 Decelerate to stop
6 Coast to stop (Emergency stop)
7 Fault reset
8 Jogging stop
1 Write enable (mainly is PKW1-PKW4 )
00 MOTOR GROUP 1 SELECTION
01 MOTOR GROUP 2 SELECTION
02 MOTOR GROUP 3 SELECTION
03 MOTOR GROUP 4 SELECTION
1 Torque control enable
0 Torque control disable
1 Electric consumption clear enable
0 Electric consumption clear disable
1 Pre-exciation enable
0 Pre-exciation disable
1 DC braking enable
0 DC braking disable
1 Heartbeat enable
0 Heartbeat disable
238
Extension card
State/Description
