INVT Goodrive300 Series Operation Manual page 103

Goodrive300 Series VFD
Function
Name
code
Keypad PID
P09.01
preset
PID feedback
P09.02
source
PID output
P09.03
feature
Detailed instruction of parameters
8: Ethernet communication set
9: Reserved
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the relative
value (0–100.0%).
Note:
Set multi-step speed, which can be compeleted
by setting P10 group parameters.
For PROFIBUS,
communication setting, corresponding extension
cards are needed.
When P09.00=0, set the parameter whose basic
value is the response value of the system.
Setting range: -100.0%–100.0%
Select the PID channel by the parameter.
0: AI1
1: AI2
2: AI3
3: HDI
4: Modbus communication feedback
5: PROFIBUS/CANopen
feedback
6: Ethernet communication feedback
7: Reserved
Note: The reference and feedback channel
cannot coincide, otherwise, PID cannot control
effectively.
0: PID output is positive: when the feedback
signal exceeds the PID given value, the output
frequency of the VFD will decrease to balance the
PID. For example, the strain PID control during
wrapup
1: PID output is negative: When the feedback
signal is stronger than the PID given value, the
output frequency of the VFD will increase to
balance the PID. For example, the strain PID
98
Ethernet, and CANopen
communication
Function parameters
Default
Modify
value
0.0%
○
0
○
0
○
