Function
Name
code
Lower output
P06.17
limit of AO1
Corresponding
P06.18 AO1 output of
lower limit
Upper output
P06.19
limit of AO1
The
corresponding
P06.20
AO1 output of
upper limit
Detailed instruction of parameters
5: Output current (relative to 2 times the rated
current of the motor)
6: Output voltage (relative to 1.5 times the rated
voltage of the VFD)
7: Output power (relative to 2 times the rated
power of the motor)
8: Set torque value (relative to 2 times the rated
torque of the motor)
9: Output torque (relative to 2 times the rated
torque of the motor)
10: Analog AI1 input value
11: Analog AI2 input value
12: Analog AI3 input value
13: Input value of high-speed pulse HDI
14: Modbus communication set value 1
15: Modbus communication set value 2
16: Set value 1
communication
17: Set value 2
communication
18: Set value 1 of Ethernet communication
19: Set value 2 of Ethernet communication
20–21: Reserved
22: Torque current (corresponding to triple the
rated current of the motor)
23: Ramp reference frequency (with sign)
24–30: Reserved
The above function codes define the relative
relationship between the output value and analog
output. When the output value exceeds the range
of set maximum or minimum output, it will count
according to the low-limit or upper-limit output.
When the analog output is current output, 1mA
equals to 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
See each application for detailed information.
80
of PROFIBUS/CANopen
of PROFIBUS/CANopen
Function parameters
Default
Modify
value
0.0%
○
0.00V
○
100.0%
○
10.00V
○
