INVT Goodrive300 Series Operation Manual page 96

Goodrive300 Series VFD
Function
Name
code
P08.19 Set length
P08.20 Actual length
Pulse per
P08.21
rotation
P08.22 Alxe perimeter
P08.23 Length ratio
Length
P08.24 correcting
coefficient
Set count
P08.25
value
Specified
P08.26
count value
Detailed instruction of parameters
corresponds to the sudden jumping frequency.
The raising time of the traverse frequency: The
time from the lowest point to the highest one.
The declining time of the traverse frequency: The
time from the highest point to the lowest one.
Setting range
(corresponding to the set frequency)
Setting range
(corresponding to the traverse range)
Setting range of P08.17: 0.1–3600.0s
Setting range of P08.18: 0.1–3600.0s
The function codes of setting length, actual length
and unit pulse are mainly used to control the fixed
length.
The length is counted by the pulse signal of HDI
terminals input and the HDI terminals are needed
to set as the length counting input.
Actual length＝the length counting input pulse
/unit pulse
When the actual length P08.20 exceeds the set
length P08.19, the multi-function digital output
terminals will output ON.
Setting range of P08.19: 0–65535m
Setting range of P08.20: 0–65535m
Setting range of P08.21: 1–10000
Setting range of P08.22: 0.01–100.00cm
Setting range of P08.23: 0.001–10.000
Setting range of P08.24: 0.001–1.000
The counter works based on the input pulse
signals of the HDI terminals.
When the count value reaches the specified
number, the multi-function output terminal sends
the signal of "The speficied count value is
reached" and the counter continues to count;
when the count value reaches the set number, the
multi-function output terminal sends the signal of
"The set count value is reached", and the counter
will be reset to zero and recount when the next
91
of P08.15: 0.0–100.0%
of P08.16: 0.0–50.0%
Function parameters
Default
Modify
value
0m
○
0m
●
1
○
10.00
○
cm
1.000
○
1.000
○
0
○
0
○
