Goodrive300 Series VFD
High bit of CRC
The RTU response command is:
START
ADDR
High bit of write data
Low bit of write data
High bit of data number
Low bit of data number
Low bit of CRC
High bit of CRC
10.4.5 The definition of data address
The address definition of the communication data in this part is to control the running of the VFD and
get the state information and related function parameters of the VFD.
10.4.5.1 Function code address representation rules
The parameter address occupies 2 bytes with the fact that the high bit is in the front and the low bit is
in the behind. The range of high and low byte are: high byte—00–ffH; low byte—00–ffH. The high byte
is the group number before the radix point of the function code and the low byte is the number after
the radix point. But both the high byte and the low byte should be changed into hex. For example
P05.06, the group number before the radix point of the function code is 05, then the high bit of the
parameter is 05, the number after the radix point 06, then the low bit of the parameter is 06, then t he
function code address is 0506H and the parameter address of P10.01 is 0A01H.
Function
Name
code
Simple
PLC
Simple
PLC
P10.01
memory
Note: P29 group is the factory parameter which cannot be read or changed. Some parameters cannot
be changed when the VFD is in the running state and some parameters cannot be changed in any
state. The setting range, unit and related instructions should be paid attention to when modifying the
function code parameters.
Besides, EEPROM is stocked frequently, which may shorten the usage time of EEPROM. For users,
END
CMD
END
Description
0: Stop after running once
1: Run at the final value after running once
2: Cycle running
0: Power loss without memory
1: Power loss with memory
T1-T2-T3-T4 (transmission time of 3.5 bytes)
T1-T2-T3-T4 (transmission time of 3.5 bytes)
T1-T2-T3-T4 (transmission time of 3.5 bytes)
Setting
217
Communication protocol
6EH
02H
10H
00H
04H
00H
02H
C5H
6EH
Default
Modify
range value
0–2 0
0–1 0
Serial
No.
354.
355.
