INVT Goodrive300 Series Operation Manual page 60

Goodrive300 Series VFD
Function
Name
code
Mutual
inductance of
P02.09
asynchronous
motor 1
Non-load
current of
P02.10
asynchronous
motor 1
Magnetic
saturation
P02.11 coefficient 1
for the iron
core of AM1
Magnetic
saturation
P02.12 coefficient 2
for the iron
core of AM1
Magnetic
saturation
P02.13 coefficient 3
for the iron
core of AM1
Magnetic
saturation
P02.14 coefficient 4
for the iron
core of AM1
Rated power
P02.15
synchronous
motor 1
Rated
frequency of
P02.16
synchronous
motor 1
Detailed instruction of parameters
0.1–6553.5 mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
of
0.1–3000.0kW
0.01Hz–P00.03
(Max. frequency)
change this group of
parameters at will.
Set the parameters of the
controlled synchronous motor
(SM).
To ensure the
performance, se the values of
P02.15 to P02.19 properly
according to the parameters
on the name plate of the SM.
55
Function parameters
Default
Modify
value
Depend
on
model
Depend
on
model
80.0%
68.0%
57.0%
40.0%
Depend
on
model
control
50.00
Hz
○
○
◎
◎
◎
◎
◎
◎
