INVT Goodrive300 Series Operation Manual page 123

Goodrive300 Series VFD
Function
Name
code
Communicatio
P14.06
n processing
P15 Group PROFIBUS/CANopen function
P15.00 Module type
Module
P15.01
address
PZD2
P15.02
receiving
PZD3
P15.03
receiving
PZD4
P15.04
receiving
PZD5
P15.05
receiving
PZD6
P15.06
receiving
PZD7
P15.07
receiving
PZD8
P15.08
receiving
Detailed instruction of parameters
0x00–0x11
LED ones:
0: Write with response: the VFD will respond to all
reading and writing commands of the upper
monitor.
1: Write without response: the VFD only responds
to the reading command other than the writing
command of the drive. The communication
efficiency can be increased by this method.
LED tens:
0: Communication encrypting is invalid
1: Communication encrypting is valid
0: PROFIBUS
1: CANopen
Select communication protocol
0–127
This function code is used to designate the
address of the VFD.
Note: 0 is the broadcast address, when set it as
broadcast address, only receive the radio
command of the upper monitor other than
answering the upper monitor.
0: Invalid
1: Setting frequency (0–Fmax(unit:0.01Hz))
2: PID reference,
corresponds to 100.0%)
3: PID feedback,
corresponds to 100.0%)
4: Torque setting (-3000–3000,1000 corresponds
to 100.0% the rated current of the motor)
5: Upper frequency of forward rotation (0–Fmax
unit:0.01Hz))
6: Upper frequency
(0–Fmax(unit:0.01Hz))
7: Electromotion torque upper limit (0–3000,1000
corresponds to 100.0%of the rated current of the
118
range (0–1000,
range (0–1000,
of reverse rotation
Function parameters
Default
Modify
value
0x00
○
0
◎
2
◎
0
○
1000
0
○
1000
0
○
0
○
0
○
0
○
0
○
