Goodrive300 Series VFD
Function
code
Keypad setting for
upper frequency of
P03.16
forward rotation in
torque control
Keypad setting for
upper frequency of
P03.17
reverse rotation in
torque control
electromotion
P03.18
torque limit setting
Upper braking
P03.19 torque limit setting
Keypad setting of
P03.20
electromotion
torque limit
Keypad setting of
P03.21 upper braking
torque limit
P17.09 Output torque
P17.15 Torque reference

7.6 Parmeters of the motor

• Physical accident may occur if the motor starts up suddenly during autotune.
Please check the safety of surrounding environment of the motor and the load
before autotune.
• The power is still applied even the motor stops running during static autotune.
Please do not touch the motor until the autotune is completed, otherwise there
would be electric shock.
Name
9: Reserved
0.00Hz–P00.03 (Max. frequency)
0.00 Hz–P00.03 (Max. frequency)
Upper 0: Keypad setting upper-limit frequency (P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
source
2: AI2
3: AI3
4: HDI
5: Modbus communication
6: PROFIBUS/CANopen communication
source
7: Ethernet communication
8: Reserved
upper
0.0–300.0% (rated current of the motor)
0.0–300.0% (rated current of the motor)
-250.0–250.0%
-300.0–300.0% (rated current of the motor)
Detailed instruction of parameters
141
Basic operation instruction
Default
value
50.00 Hz
50.00 Hz
0
0
180.0%
180.0%
0.0%
0.0%
