When the user selects the user-defined V/F curve function in Goodrive300 series VFDs, they can set
the given channel of voltage and frequency and the corresponding ACC/DEC time, or the two can
combinate to form a real-time curve.
Note: the application of V/F curve separation can be used in many cases with various kinds of power
supply of the VFD. But the users should set and adjust the parameters with caution. Incorrect
parameters may cause damage to the VFD.
Function
code
P00.00 Speed control mode
P00.03 Max. output frequency
Upper limit of the running
P00.04
Lower limit of the running
P00.05
P00.11
P00.12
P02.00
P02.02
asynchronous motor 1
P02.04
asynchronous motor 1
P04.00 Motor 1 V/F curve setting
P04.01 Torque boost of motor 1
Torque boost close of
P04.02
P04.03
Name
frequency
frequency
ACC time 1
DEC time 1
Type of motor 1
Rated frequency of
Rated voltage of
motor 1
V/F
Description
0: Sensorless vector control mode 0
(applicable to AM and SM)
1: Sensorless vector control mode 1
(applicable to AM)
2: SVPWM control mode (applicable to
AM and SM)
P00.04–400.00Hz
P00.05–P00.03
0.00Hz–P00.04
0.0–3600.0s
0.0–3600.0s
0: Asynchronous motor
1: Synchronous motor
0.01Hz–P00.03 (Max. output frequency)
0–1200V
0: Straight line V/F curve
1: Multi-dots V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
5: Customized V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
0.0%–50.0% (rated frequency of motor 1)
0.00Hz–P04.05
136
Basic operation instruction
Default
value
1
50.00Hz
50.00Hz
0.00Hz
Depend
on model
Depend
on model
0
50.00Hz
Depend
on model
0
0.0%
20.0%
0.00Hz
