Goodrive300 Series VFD
Function
code
P08.04
P08.05
P08.28 Automatic fault reset times 0–10
Interval time of automatic
P08.29

7.8 Frequency setting

Goodrive300 series VFDs can set the frequency by various means. The given channel can be divided
into main given channel and assistant given channel.
There are two mian given channels: A frequency given channel and B frequency given channel.
These two given channels can carry out mutual simple math calculation between each other. And the
given channels can be shifted dynamically through set multi-funciton terminals.
There are three assistane given channels: keypad UP/DOWN input, terminals UP/DOWN switch input
and digital potentiometer input. The three ways equal to the effect of input UP/DOWN given in internal
assistant given of the VFD. The user can enable the given method and the effect of the method to the
frequency given by setting function codes.
The actual given of the VFD is comsisted of main given channel and assistant given channel.
Name
ACC time 4
DEC time 4
fault reset
Detailed instruction of parameters
0.0–3600.0s
0.0–3600.0s
0.1–3600.0s
152
Basic operation instruction
Default
value
Depend
on model
Depend
on model
0
1.0s
