INVT Goodrive300 Series Operation Manual page 107

Goodrive300 Series VFD
Function
Name
code
of ACC/DEC
time
PID output
P09.16
filter time
P10 Group Simple PLC and multi-step speed control
P10.00 Simple PLC
Simple PLC
P10.01
memory
Multi-step
P10.02
speed 0
Running time
P10.03
of step 0
Multi-step
P10.04
speed 1
Running time
P10.05
of step 1
Multi-step
P10.06
speed 2
Running time
P10.07
of step 2
Multi-step
P10.08
speed 3
Running time
P10.09
of step 3
Multi-step
P10.10
speed 4
Running time
P10.11
of step 4
P10.12 Multi-step
Detailed instruction of parameters
0.000–10.000s
0: Stop after running once. The VFD has to be
commanded again after finishing a cycle.
1: Run at the final value after running once. After
finish a signal, the VFD will keep the running
frequency and direction of the last run.
2: Cycle running. The VFD will keep on running
until receiving a stop command d. And then, the
system will stop.
0: Power loss without memory
1: Power loss with memory; PLC record the
running stage and frequency when power loss.
The frequency setting range of stage 0–15:
-100.0–100.0%，100.0% of the frequency setting
corresponds to the Max. Frequency P00.03.
The operation time setting of stage 0–15: the time
unit is determined by P10.37. When selecting
simple PLC running, set P10.02–P10.33 to define
the running frequency and time of all stages.
Note: The symbol of multi-step determines the
running direction of simple PLC. The negative
value means reverse rotation.
DEC time
(2 stages)
P10.04
P10.02
ACC time
(2 stags)
P10.03 P10.05 P10.07
If multi-step speed
multi-step speeds are in the range of --f
and it can be set continuously.
Goodrive300 series VFDs can set 16 stages
speed, selected by the combination of multi-step
102
P10.28
P10.30
P10.06
P10.31 P10.33
operation is selected,
max
Function parameters
Default
Modify
value
0.000s
0
0
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
P10.32
0.0%
0.0s
0.0%
–f
max
0.0s
0.0%
○
○
○
○
○
○
○
○
○
○
○
○
○
○
