Goodrive300 Series VFD
Function
Name
code
P06 Group Output terminals
P06.00 HDO output
P06.01 Y1 output
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Detailed instruction of parameters
The function selection of the high-speed pulse
output terminals.
0: Open collector high speed pulse output: The
Max.pulse frequency
P06.27–P06.31 for detailed information of the
related functions.
1: Open collector output. See P06.02 for detailed
information of the related functions.
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Set count value reached
19: Specified count value reached
20: External fault valid
21: Length arrival
22: Running time arrival
23: Modbus communication virtual terminals
output
24: PROFIBUS/CANopen communication virtual
terminals output
25: Ethernet communication virtual terminals
78
is 50.0kHz. See
Function parameters
Default
Modify
value
0
◎
0
○
0
○
1
○
5
○
